Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height

Name: Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height
Brand: Wuxi Wondery Industry Equipment Co., Ltd
Price: 25.00 USD
Availability: InStock

Nom De La Marque:	WONDERY
MOQ:	1
Prix:	$23,000-27,000

Informations détaillées

Description du produit

Informations détaillées

Lieu d'origine:

Jiangsu

Poids:

3200kg

Hauteur du noyau:

1050 mm

Largeur du noyau:

1000 mm

Épaisseur maximale:

120 mm

Dents serrées:

100 pièces

Alimentation électrique:

AC-220V; 50Hz

Dimensions:

2400 × 2200 × 2200 mm

Système de contrôle:

PLC et écran tactile

Commutateur de proximité:

Omron, Japon

Guide linéaire:

TBI, Taiwan

Composants pneumatiques:

Airtac, Taiwan

PLC et HMI:

Delta, Taïwan

Servomoteur:

Delta, Taïwan

Contacteur:

Schneider, Chine

Principe de travail:

Pousser, presser et décrocher

Mettre en évidence:

aluminum radiator crimping machine

servo radiator fin machine

1050mm core height crimper

Description du produit

Servo Type Aluminum Radiator Plastic Tank Crimping Machine

High Efficiency Crimping Solution

The aluminum radiator plastic tank crimping clinching machine is designed for crimping the teeth of header plates and securely locking plastic tanks to the core body. This creates a sealed space between the crimped plastic tank, sealing gasket, and header plate. Our servo-controlled machine handles products of various specifications with precision and efficiency.

Key Features

PLC controlled with HMI screen for easy operation
Servo and pneumatic power system for automatic 4-side clinching
Automatic dodging function to prevent collision with water pipes
Programmable for different radiator specifications
Quick-change clinching tools for different tank sizes
Comprehensive safety features including alarm lamp and photoelectric sensors

Technical Specifications

Specification	Value
Max core height	1050mm (customizable)
Max core width	1000mm (customizable)
Maximum thickness	120mm (customizable)
Max crimped teeth quantity	100 pieces
Power supply	AC-220V, 50Hz
Dimensions	2400×2200×2200mm
Weight	Approx. 3200kg

Premium Components

Proximity switch: Omron, Japan

Linear guide and ball screw: TBI, Taiwan

Pneumatic components: AIRTAC, Taiwan

PLC and HMI: Delta, Taiwan

Servo motor & driver: Delta, Taiwan

Electrical components: Schneider, China

Operation Highlights

Precise crimping program setup via touch screen interface
Real-time working status monitoring
Separate long-header and short-header crimping devices
Advanced movement capabilities including dodge and step-forward moves

About Wuxi Wondery Industry Equipment Co., Ltd.

We are a professional supplier of industrial machines serving various industries including automotive, HVAC, and power generation. Established in 2008, we specialize in radiator manufacturing equipment and offer comprehensive services including technical consultation, installation, training, and maintenance. Our machines have been exported worldwide to countries including USA, Australia, Mexico, India, and many others.

Frequently Asked Questions

What is the power supply requirement?

The power supply can be adjusted to match your local requirements through a transformer or direct voltage matching.

What information is needed for quotation?

Please provide technical requirements, drawings, pictures, industrial voltage, and planned output.

What are the payment terms?

40% down payment, 60% before delivery (T/T transfer).

What is the delivery time?

30-60 days after receipt of down payment.
